STM32F103C8T6 ARM Microcontroller Minimum System Development Board Type C

STM32F103C8T6 ARM Microcontroller Minimum System Development Board Type C

First Come First Serve Offer (T&C Apply )

179.34
249.00 179.34
Sale Sold out
Shipping calculated at checkout.

STM32F103C8T6 ARM Microcontroller Minimum System Development Board Type C

The STM32F103C8T6 Type-C Imported Blue Pill Board is a high-performance microcontroller development platform that features the STMicroelectronics STM32F103C8T6 chipset, equipped with an ARM Cortex-M3 processor running at 72MHz and 64KB Flash memory. This board is ideal for a wide range of applications including IoT, robotics, automation, and embedded systems development. It is known for its reliable performance and robust capabilities, making it a popular choice among developers working on both simple and complex projects.

One of the standout features of this board is the USB Type-C interface, which ensures faster and more secure data transfer compared to traditional Micro-B USB connections, providing enhanced efficiency in communication and power delivery. The board comes with a comprehensive set of peripherals such as USART, SPI, I2C, ADCs, and PWM timers, making it a highly versatile option for a variety of embedded system applications.

Whether you're a beginner or an experienced professional in embedded system programming, the STM32F103C8T6 Blue Pill provides an easy-to-use yet powerful platform to build and test your projects. Its flexibility and high-performance capabilities make it an excellent choice for developers seeking to create reliable and efficient embedded solutions.

Technical Details

  • Microcontroller: STM32F103C8T6 (Domestic chips)
  • Core: ARM Cortex-M3 (32-bit)
  • Header Unsoldered
  • Clock Speed: 72MHz
  • Flash Memory: 64KB
  • SRAM: 20KB
  • Operating Voltage: 2V - 3.6V
  • USB Connectivity: Type-C
  • Communication Interfaces: USART, I2C, SPI, USB, CAN
  • GPIOs: Up to 37 (5V tolerant)
  • ADC: 12-bit (up to 16 channels)
  • Operating Temperature: -40°C to 85°C
  • PCB Color: Blue
  • Product Size: 53.34x22.5x11.5mm
  • Weight (g): 7

Features

  • Microcontroller: STM32F103C8T6 (Domestic Chips). A 32-bit microcontroller, based on the ARM Cortex-M3 architecture, commonly used for embedded systems.
  • Cortex-M3 Processor: Operates at 72MHz, providing high-speed computation for real-time applications.
  • Type-C USB Connectivity: Faster and more reliable than Micro-B USB for power and data transfer.
  • Versatile Memory Storage: 64KB Flash Memory for program storage. 20KB SRAM for efficient data processing.
  • Comprehensive Communication Interfaces: 2x I2C, 2x SPI, 3x USART, CAN, USB for seamless external device integration.
  • Multiple Timer Options: Includes PWM and advanced timers for motor control and automation projects.
  • Dual 12-bit ADCs: Supports multiple sensor inputs with high precision.
  • Up to 37 I/O Pins: Almost all pins are 5V tolerant, making it easier to interface with external devices.
  • Low Power Consumption: Features Sleep, Stop, and Standby modes for energy-efficient applications.

Drawing

drawing

Pin Out

pin out

Applications

  • IoT Development
  • Robotics & Automation
  • Smart Home Projects
  • Embedded System Prototyping
  • Motor Control & Industrial Automation
  • Medical & Handheld Devices

Physical Attribute

  • Product Size: 53.34x22.5x11.5mm
  • Weight (g): 7

Package Includes

  • 1 x STM32F103C8T6 ARM Microcontroller Minimum
  • 2 x 20 Pin Male Header
