Mornsun LIF480-10B24R2 AC/DC 480W DIN-Rail Power Supply

Mornsun LIF480-10B24R2 AC/DC 480W DIN-Rail Power Supply

First Come First Serve Offer (T&C Apply )

11,617.00
15,870.00 11,617.00
Sale Sold out
Shipping calculated at checkout.

Mornsun LIF480-10B24R2 AC/DC 480W DIN-Rail Power Supply

The LIF480-10B24R2 is a 480W AC/DC power supply from Mornsun. It has a universal input voltage of 85-264VAC or 120-370VDC, and an output voltage of 24V. The power supply is also equipped with a power factor correction (PFC) function, which helps to improve the efficiency of the power supply and reduce the amount of power that is wasted. The LIF480-10B24R2 is a compact and reliable power supply that is ideal for a variety of applications, including industrial automation, networking, and telecommunications.

Features:

  • Universal input voltage of 85-264VAC or 120-370VDC
  • Output voltage of 24V
  • Power factor correction (PFC) function
  • Compact and reliable design
  • DIN rail mounting

Note:

  • Unless otherwise specified, parameters in this datasheet were measured under the conditions of Ta=25℃, humidity<75%RH with nominal input voltage and rated output load
  • The room temperature derating of 5℃/1000m is needed for operating altitude greater than 2000m
  • All index testing methods in this datasheet are based on our company's corporate standards
  • In order to improve the efficiency at high input voltage, there will be audible noise generated, but it does not affect product performance and reliability
  • The out case needs to be connected to the earth ( )of system when the terminal equipment in operating
  • The output voltage can be adjusted by the ADJ, clockwise to increase
  • Our products shall be classified according to ISO14001 and related environmental laws and regulations and shall be handled by qualified units
  • The power supply is considered a component which will be installed into the final equipment. All EMC tests should be confirmed with the final equipment

Package Includes:

1 x  Mornsun LIF480-10B24R2 AC/DC 480W DIN-Rail Power Supply

Specifications:

Specification Value
Power 480W
Input voltage 85-264VAC or 120-370VDC
Output voltage 24V
Output current 20A
Isolation voltage 3000VAC
Dimensions 220 x 100 x 45mm
Weight 1.5kg
