DC 24V 40RPM 60mm Diameter 60GX Planetary Geared Industrial Grade Highly Reliable and Full Copper Center Shaft motor
DC 24V 40RPM 60mm Diameter 60GX Planetary Geared Industrial Grade Highly Reliable and Full Copper Center Shaft motor
First Come First Serve Offer (T&C Apply )
Couldn't load pickup availability
The DC 24V 40RPM 60GX Planetary Geared Motor is designed for applications that demand both efficiency and reliability at low speeds. This industrial-grade motor excels in providing high torque while maintaining smooth and controlled motion, making it ideal for various heavy-duty applications.
Key Features:
Controlled Low Speed: With a no-load speed of 40 RPM and a load speed of 38 RPM, this motor allows for precise control in applications requiring slow and steady movement.High Torque Capability: The rated torque of 50 KGF.CM ensures it can handle substantial loads, making it perfect for industrial uses.
Optimal Gearbox Ratio: The gearbox ratio of 124:1 enhances torque output while providing stable and reliable performance, suitable for tasks such as lifting and moving heavy objects.
Robust Construction: Made with full copper windings, this motor ensures durability and long-lasting performance in demanding environments.
Compact Size: The motor diameter of 60mm and a gearbox length of 65.5mm allow for versatile installation options in various setups without requiring excessive space.
Secure Mounting Design: The M6*4 mounting with a center shaft design provides stability and ease of installation.
Durable Shaft Connection: The 12mm diameter shaft ensures a secure connection and the ability to withstand significant loads during operation.
Applications:
Industrial Equipment: Perfect for use in heavy machinery that requires low-speed operation with high torque.Conveyor Systems: Ideal for conveyors that need to transport heavy items smoothly and efficiently.
Robotics: Suitable for robotic systems where precision and controlled movement are essential.
Specifications
- Operating Voltage: 24V DC
- No-Load Speed: 40 RPM
- Load Speed: 38 RPM
- Rated Torque: 50 KGF.CM
- Gearbox Ratio: 124:1
- Motor Diameter: 60mm
- Gearbox Length: 65.5mm
- Motor Length: 95mm
- Shaft Type: Center Shaft
- Mounting: M6*4
- Shaft Diameter: 12mm
- Motor Type: 60S motor
Dimensional Drawing
Package Includes
- 1 x DC 24V 40RPM 60mm Diameter 60GX Planetary Geared Industrial Grade Highly Reliable and Full Copper Center Shaft motor
