DC 24V 2.6RPM 60mm Diameter 60GX Planetary Gear motor full copper industrial grade
DC 24V 2.6RPM 60mm Diameter 60GX Planetary Gear motor full copper industrial grade
First Come First Serve Offer (T&C Apply )
Couldn't load pickup availability
The DC 24V 2.6RPM 60GX Planetary Gear Motor is engineered for precision applications that require extremely low-speed operation combined with high torque. Its industrial-grade design and full copper construction ensure both reliability and efficiency in various demanding environments.
Key Features:
Ultra-Low Speed: With a no-load speed of 2.6 RPM and a load speed of 2.5 RPM, this motor is perfect for applications needing controlled movement at very low speeds.High Torque Capacity: Rated at 100 KGF.CM, is capable of handling heavy loads with ease, making it suitable for demanding tasks.
Efficient Gearbox Design: The planetary gearbox with a ratio of i763 significantly enhances torque output while reducing the speed, ideal for applications that require high precision and force.
Robust Construction: Built with full copper windings and durable materials to ensure long-lasting performance, even in challenging conditions.
Compact Size: Its 60mm diameter and compact design facilitate easy integration into various systems.
Secure Mounting: Features an M6*4 mounting configuration, allowing for stable and secure installation in a range of applications.
Applications:
Robotics: Excellent for robotic arms and automated systems requiring precise positioning and high torque at low speeds.Heavy-Duty Machinery: Suitable for industrial equipment and machinery where reliable low-speed operation is necessary.
Automated Systems: Ideal for conveyor systems, lifting mechanisms, and any application needing controlled movement.
Specifications
- Operating Voltage: 24V DC
- No-Load Speed: 2.6 RPM
- Load Speed: 2.5 RPM
- Rated Torque: 100 KGF.CM
- Gearbox Ratio: i763
- Motor Diameter: 60mm
- Gearbox Length: 81.5mm
- Motor Length: 95mm
- Shaft Type: Center Shaft
- Mounting: M6*4
- Shaft Diameter: 12mm
- Motor Type: 60S motor
Dimensional Drawing
Package Includes
- 1 x DC 24V 2.6RPM 60mm Diameter 60GX Planetary Gear motor full copper industrial grade
