DC 24V 2.5RPM 37mm Diameter GB37 eccentric Shaft Geared Industrial Grade Highly Reliable and Full Copper Motor

DC 24V 2.5RPM 37mm Diameter GB37 eccentric Shaft Geared Industrial Grade Highly Reliable and Full Copper Motor

First Come First Serve Offer (T&C Apply )

832.02
1,199.00 832.02
Sale Sold out
Shipping calculated at checkout.
The DC 24V 2.5RPM 37mm GB37 Eccentric Shaft Geared Motor is designed for applications requiring extremely low speed and high torque. With a no-load speed of just 2.5 RPM and a load speed of 2.5 RPM, this motor excels in precise control tasks. The high gearbox ratio of 981:1 allows for significant torque output, making it suitable for applications that involve heavy loads or require careful manipulation.

Key Features:

Full Copper Motor Construction: Offers superior reliability and durability, with efficient heat management.

Extremely Low Speed: Operates at 2.5 RPM, ideal for applications needing high precision and slow movements.

High Torque Output: Provides a rated torque of 10 Kgf. cm, effective for handling heavy loads.

Efficient Gearbox Design: The 981:1 gearbox ratio ensures effective power transfer and control at low speeds.

D-Type Eccentric Shaft: Facilitates easy mounting and alignment in various configurations.

Applications:

Industrial Automation: Suitable for conveyor systems or machinery requiring slow, controlled movements.

Robotics: Ideal for robotic arms or mechanisms where precision positioning is crucial.

Material Handling: Effective in systems involving the transport of heavy materials at low speeds.

Home Automation: Can be used in automated systems for doors, gates, or curtains that require careful movement.

Testing Equipment: Useful in devices that require slow, consistent operation for testing processes.


Technical Details

  • Operating Voltage: 24V DC
  • No-Load Speed: 2.5 RPM
  • Load Speed: 2.5 RPM
  • Rated Torque: 10 Kg. cm
  • Gearbox Ratio: 981:1
  • Gearbox Length: 31mm
  • Motor Diameter: 37mm
  • Shaft Type: 6mm D-Type (Eccentric side shaft)
  • Rotation Direction: CCW (Counterclockwise)
  • Current Rating: Approx. 3A under load

Dimensional Drawing

DC 24V 2.5RPM 37mm Diameter GB37 eccentric Shaft Geared full copper industrial grade motor

Package Includes

  • 1 x DC 24V 2.5RPM 37mm Diameter GB37 eccentric Shaft Geared Industrial Grade Highly Reliable and Full Copper Motor
