3DR Radio Telemetry 915 MHz

3DR Radio Telemetry 915 MHz

First Come First Serve Offer (T&C Apply )

7,299.00
7,499.00 7,299.00
Sale Sold out
Shipping calculated at checkout.

3DR Radio Telemetry 915 MHz

This 3DR 915 MHz Radio Telemetry kit set allows you to connect a flight controller and a USB or UART-enabled device, such as a computer, laptop, or tablet with USB compatibility (OTG).

The latest version 2 radios no longer require a separate Air/Ground module, as both transceivers can now use both UART or USB connections, and support both modes.

This radio set not only allows you to view real-time data, such as live GPS position overlaid on a map, system voltage, heading, waypoint navigation, and even an artificial horizon, but also offers much more.

By using an open-source MAVlink-based ground station software, you can even fly your aircraft with a joystick via your computer and update settings in real time. Alternatively, you can use it for your DIY projects that require a wireless Serial interface.

This kit is cost-effective, has a longer range, and offers superior performance. The system operates on the 915 MHz band and provides a full-duplex link using HopeRF’s HM-TRP modules running custom, open-source firmware.

Features

  • MAVLink protocol framing status documents
  • Frequency modulation and Spread Spectrum (FHSS)
  • Self-adaption to time division multiplexing
  • Support LBT and AFA
  • Configurable duty cycle
  • Built-in error correcting code(up to 25% data bit error)
  • AT command configure data transmission
  • RT command remote control data transmission
  • Interchangeable air and ground 915 MHz modules
  • Micro-USB port
  • 6-position Molex connector
  • SMA connector
  • 2-way full-duplex communication through adaptive TDM
  • UART interface
  • Transparent serial link
  • Open-source SIK firmware
  • Configurable through *Mission Planner and *APM Planner
  • Based on the HM-TRP wireless module, with Si1000 8051 microcontroller and Si4432

Package Includes:

  • 2 x Radio Telemetry 915 MHz
  • 1 x 30cm Type C to Type C cable
  • 1 x 30cm Micro USB to Type C cable
  • 2 x Lead cable
  • 2 x TX433-JK-11 Antenna

Specifications:

Frequency Range

915 MHz
Sensitivity (dBm)

-124
Operating Voltage (VDC)

3 ~ 6
Max. Operating Current (mA)

500
Module Size (LxWxH) mm

54 x 260 x 12
Antenna Length (mm)

110
Weight (gm)

33
