25GA370 60 RPM 12V 25mm Diameter centre D-Shaft DC high torque geared motor

25GA370 60 RPM 12V 25mm Diameter centre D-Shaft DC high torque geared motor

First Come First Serve Offer (T&C Apply )

391.02
599.00 391.02
Sale Sold out
Shipping calculated at checkout.

The 25GA370 is a high-torque reduction motor that operates at 12V DC with a no-load speed of 60 RPM. This motor is designed for applications requiring a balance of speed and torque, making it well-suited for various mechanical and robotic systems. The motor's compact 25mm diameter gearbox and robust construction ensure reliable performance in precision-driven tasks.

Features:

High Torque Output: Delivers substantial force at a moderate speed, making it ideal for various demanding applications.

Durable Construction: The motor’s metal gearbox ensures long-lasting performance and reliability.

Precision Engineering: Provides smooth and controlled operation with minimal backlash.

Compact Design: A small form factor with a 25mm gearbox makes integrating into various design projects easy.

Energy Efficient: Optimized to operate efficiently at 12V, drawing minimal current, suitable for battery-powered applications.

Technical Details

  • Reduction Ratio:103
  • Rated Voltage(DC): 12
  • No Load Speed (RPM):60
  • No Load Current(A): 0.06
  • Rated Speed(RPM):46
  • Rated Current(A):0.30
  • Rated Torque(KG-CM):2.7
  • Rated Power(W):3.6
  • Stall Torque(KG-CM):8.2
  • Stall Current(A):1.3
  • Gearbox length:23mm

Applications:

Robotics: Ideal for robotic arms, drive systems, and other components that require controlled, moderate-speed movement.

Automation Systems: Suitable for automated mechanisms needing a balance of speed and torque, such as conveyor belts, winches, or linear actuators.

Model Making: Perfect for model builders who need motors that provide realistic movement at moderate speeds with high torque.

DIY and Hobby Projects: These are great for custom machines, DIY robots, and personal projects requiring reliable motors with balanced speed and torque.

Industrial Equipment: Suitable for small-scale industrial machinery where a precise, high-torque motor with moderate speed is necessary.

Package Includes

  • 1 x 25GA370 60 RPM 12V 25mm Diameter centre D-Shaft DC high torque geared motor
