25GA370 35 RPM 12V 25mm Diameter centre D-Shaft DC high torque geared motor

25GA370 35 RPM 12V 25mm Diameter centre D-Shaft DC high torque geared motor

First Come First Serve Offer (T&C Apply )

399.00
599.00 399.00
Sale Sold out
Shipping calculated at checkout.

The 25GA370 is a high-torque reduction motor designed to operate at 12V DC, providing a no-load speed of 35 RPM. This motor is well-suited for applications requiring controlled, slow-speed movement with significant torque. With a compact 25mm diameter gearbox and robust metal construction, it is an excellent choice for various precision-driven projects in robotics, automation, and more.

Features:

High Torque Output: Designed to deliver substantial force at low speeds.

Durable Construction: The motor’s metal gearbox ensures long-lasting performance and reliability.

Precision Engineering: Provides smooth and controlled operation with minimal backlash.

Compact Design: Small form factor with a 25mm gearbox, making it easy to integrate into tight spaces.

Energy Efficient: Optimized to operate efficiently at 12V, drawing minimal current for battery-powered applications.

Technical Details

  • Reduction Ratio:171
  • Rated Voltage(DC): 12
  • No Load Speed (RPM):35
  • No Load Current(A): 0.06
  • Rated Speed(RPM):27
  • Rated Current(A):0.30
  • Rated Torque(KG-CM):4.00
  • Rated Power(W):3.6
  • Stall Torque(KG-CM):12
  • Stall Current(A):1.3
  • Gearbox length(mm):25

Applications:

Robotics: Ideal for robotic joints, arms, and other components where slow and precise movement is critical.

Automation Systems: Suitable for automated mechanisms requiring slow, powerful motion, such as in conveyor belts, winches, or controlled drives.

Model Making: Perfect for model builders needing slow-speed motors with high torque for realistic movement.

DIY and Hobby Projects: Great for custom machines, DIY projects, and personal robotics requiring reliable, slow-moving motors.

Industrial Equipment: Suitable for small-scale industrial machinery where precise, low-speed, high-torque motors are essential.

Package Includes

  • 1 x 25GA370 35 RPM 12V 25mm Diameter centre D-Shaft DC high torque geared motor
