24V one Channel Isolated Relay Module optocoupler High and Low Level Trigger

24V one Channel Isolated Relay Module optocoupler High and Low Level Trigger

First Come First Serve Offer (T&C Apply )

79.00
119.00 79.00
Sale Sold out
Shipping calculated at checkout.

24V one Channel Isolated Relay Module optocoupler High and Low-Level Trigger

1 Channel Relay Module 24V High and Low-Level Trigger Relay Module is small and easy to use. Use it to control one 240V power appliance directly from Arduino, Raspberry Pi, and other microcontrollers or low-voltage circuits. Perfect for switching 240V appliances—lights, fans, etc.—and even high-power motors at lower voltages.<

The board uses a high-quality relay, which can handle a maximum of 10A/250 V AC or 15A/125 V AC. Each relay has all three connections—common, normally open, and normally closed—brought out to three-pin screw terminals, which make it easy to make and remove connections. The board has a power indication and a relay status LED to ease debugging. The board can accept control inputs within a wide range of voltages, from 12V to 24V. Power input and relay control signals are brought to header pins on the board. Hence, the board can be easily interfaced with our development boards using jumper wires.

Note: The actual product may vary slightly in color and components from the image shown, depending on quantity availability.

Technical Details

  • Model Type: Relay Module
  • No. of Channels: 1
  • Operating Voltage (VDC): 24
  • Length (mm): 50
  • Width (mm): 25
  • Height (mm): 20
  • Weight (g): 16

Features

  • Trigger: High or Low Level
  • High-current relay: 15A @ 125V AC or 10A @ 250V AC
  • Compatible with microcontrollers (Arduino, 8051, AVR, PIC, DSP, ARM)

Applications :

  • Home Automation: Control AC appliances like lights and fans
  • Industrial Automation: Operate heavy machinery safely
  • Motor Control: Switch motors in automation and robotics
  • Security Systems: Activate alarms, door locks, and surveillance
  • IoT Applications: Integrate with sensors for remote control
  • Smart Agriculture: Automate irrigation and water pumps

Physical Attributes

  • Length (mm): 50
  • Width (mm): 25
  • Height (mm): 20
  • Weight (g): 16

Package Includes

  • 1 x 24V one Channel Isolated Relay Module optocoupler High and Low-Level Trigger
