1 Module 15mm width x15mm high x 1metre 45 steel mechanical rack holless Only Rack

1 Module 15mm width x15mm high x 1metre 45 steel mechanical rack holless Only Rack

First Come First Serve Offer (T&C Apply )

1,249.00
1,599.00 1,249.00
Sale Sold out
Shipping calculated at checkout.

Rack gears are straight bars with gear teeth running along one side into the gear teeth of a pinion. Usually, the teeth are straight (spur rack). Rack and pinion are sometimes used instead of a trapezoidal threaded shaft and nut to move a machine head in a back-and-forth motion. The spur rack is made of 45 steel, which has high hardness, strength, and strong deformation resistance, it is more durable, longer lasting, and easier to process, install, and debug. Racks are used to convert rotary motion into linear motion. The straight teeth of the rack are cut into one face of the square or circular section of the rod and fit with the pinion, which has the characteristics of mechanical simplicity, high load-carrying capacity, and unlimited length. Spur racks are paired with spur gears and are suitable for lifting mechanisms (vertical movement), horizontal movement, positioning mechanisms, stopping, and allowing simultaneous rotation of multiple axes in industrial machinery.

Key Features:

Material: 1 Module 45 Steel

Tooth Configuration: Straight teeth

Mounting Holes: None (Holless design)

Finish: Polished steel for rust resistance and smooth operation

Load Capacity: Suitable for medium to heavy loads, specific capacity varies based on application requirements.

Benefits:

Durability: Crafted from robust 1 Module 45 steel for long-lasting performance.

Precision Engineering: Accurate tooth configuration ensures efficient operation.

Versatile Use: Ideal for a variety of mechanical and engineering applications.

Corrosion Resistance: A polished finish enhances durability and reduces friction

Installation Instructions:

Compatibility: Ensure compatibility with your gear and mounting system.

Surface Preparation: Thoroughly clean the mounting surface to remove debris and ensure a secure fit.

Alignment: Properly align the rack with the gear to ensure smooth meshing of teeth.

Mounting: Secure the rack using appropriate mounting brackets or custom mounts to ensure stability and optimal performance.

Maintenance:

Inspection: Regularly inspect the rack for signs of wear and tear, especially on the tooth profile.

Lubrication: Apply lubrication to the teeth periodically to maintain smooth operation and extend the rack's lifespan.

Technical Details

  • Material Type: 1 Mold 45 Steel
  • Overall Length: 1000 mm
  • Rack Width: 15 mm
  • Rack Height: 15 mm
  • Tooth Pitch: 3.14 mm
  • Tooth Depth: 2.25 mm
  • Tooth Configuration: Straight teeth
  • Mounting Holes: None (Holless design)
  • Load Capacity: Suitable for medium to heavy loads (Specific load capacity dependent on application)
  • Surface Treatment: Polished for reduced friction and enhanced durability

Physical Attributes

  • L x W x H (mm): 1000 x 15 x 15
  • Weight (gm): 1626

Package Includes

  • 1 x 1 Module 15mm width x15mm height x 1000mm 45 steel mechanical rack holless Only Rack
